**Please read the paper on the following link:**

https://1worldcontent.com/ess/9256.pdf

**Abstract:**

This paper presents a single-chip high-voltage transceiver ASIC for low-ﬁeld NMR spectroscopy. The chip integrates an adjustable high-voltage (HV) H-bridge power ampliﬁer (PA) with a PLL frequency synthesizer and a quadrature low intermediate frequency (low-IF) receiver, achieving a measured input-referred voltage noise density of 1.1 nV/√Hz. The operating frequency of the chip is from 0.1 MHz to 200 MHz, supporting all relevant Larmor frequencies for low-ﬁeld mobile and portable NMR. The PA consists of four isolated 50 V NMOS transistors, isolated gate drivers with a digitally adjustable deadtime control, high-frequency level shifters, and a TX-control logic that supports bootstrapping of the integrated high-side drivers. The output current can be deﬁned by an adjustable voltage supply from 0 V to 50 V, delivering a maximum current of 2.0 A_pp into a non-tuned 3 mm NMR coil and up to 8.3 A_pp into a parallel tuned NMR coil. Inside a custom-designed 1.1 T portable NMR magnet, the system achieves a spin sensitivity of 1.1 × 10^16 spins/√Hz and a concentration sensitivity of 1 mM/√Hz.

ESSCIRC ESSDERC 2021

A 0.1 MHz to 200 MHz High-Voltage CMOS Transceiver for Portable NMR Systems with a Maximum Output Current of 2.0 App

nmr-on-chip

nmr-on-a-chip

nmr transceiver

benchtop nmr

mobile nmr

cmos-based nmr

portable nmr

The aim of ESSCIRC and ESSDERC is to provide an annual European forum for the presentation and discussion of recent advances in solid-state devices and circuits.
The level of integration for system-on-chip design is rapidly increasing.

This is made available by advances in semiconductor technology. Therefore, more than ever before, a deeper interaction among technologists, device experts, IC designers, and system designers is necessary. ESSCIRC and ESSDERC are governed by a common Steering Committee and share Plenary Keynote Presentations and Joint Sessions bridging both device and circuit communities.

Highlights:
* 3 joint keynote presentations
* 3 keynote presentations ESSCIRC
* 3 keynote presentations ESSDERC
* Invited papers with overall coverage of all aspects of advanced devices and circuits
* Presentation of IEEE and ESSCIRC/ESSDERC Awards
* Educational Events

JOINT PLENARY talks live broadcast: September 13, 2021<br>
ESSCIRC and ESSDERC KEYNOTE talks live broadcast: September 15, 2021<br>
LIVE Q&A INTERACTIVE sessions for all Conference Technical sessions: September 14 – 16 – 17, 2021<br>
LIVE Q&A INTERACTIVE sessions for all Educational Events: September 20-21-22, 2021<br>
(on demand videos available from September 6 until November 30, 2021)

**Please see here for the [ESSCIRC Guide](https://drive.google.com/file/d/10dghzuv4aQBty4QfTIY9Q8hXyqsue8Le/view?usp=sharing), [ESSDERC Guide](https://drive.google.com/file/d/10dx9y2tm9cHPDa4upNUYjfXCf44aPry5/view?usp=sharing), and the [Program at a Glance](https://drive.google.com/file/d/10eU0OLTXEpiNzI5hkqv4mSr43T8cedPP/view?usp=sharing)**


To access ESSCIRC ESSDERC 2021, you must pre-register for the conference.  Instructions on how to access the event will be provided directly to attendees and included on the ESSCIRC ESSDERC conference website. [Register now](https://www.esscirc-essderc2021.org/).

Please register for the ESSCIRC conference to join the event.

The aim of ESSCIRC and ESSDERC is to provide an annual European forum for the presentation and discussion of recent advances in solid-state devices and circuits.
The level of integration for system-on-chip design is rapidly increasing.

This is made available by advances in semiconductor technology. Therefore, more than ever before, a deeper interaction among technologists, device experts, IC designers, and system designers is necessary. ESSCIRC and ESSDERC are governed by a common Steering Committee and share Plenary Keynote Presentations and Joint Sessions bridging both device and circuit communities.





technical paper

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9169.pdf

**Abstract:**

This paper presents a CMOS circular-geometry quad-core voltage-controlled oscillator (VCO) with class-F operation and tail filtering to achieve ultra low phase noise in K band. The use of class-F operation in a circular-geometry multi-core VCO further lowers phase noise but results in new mode ambiguity. We introduce cross-coupled narrow and thin metal traces in the class-F transformer secondary loop to suppress this new mode ambiguity. Also, we extend the circular geometry design to the VCO tail LC filters, reducing the chip area. A proof-of-concept prototype is fabricated in a standard 65 nm CMOS technology. In measurement, the VCO operates from 17.9 to 20.7 GHz. At 19 GHz, the VCO achieves a phase noise of -115 dBc/Hz at 1 MHz offset with a figure of merit (FoM) of -188.4 dBc/Hz.

A 19 GHz Circular-Geometry Quad-Core Tail-Filtering Class-F VCO with -115 dBc/Hz Phase Noise at 1 MHz Offset in 65-nm CMOS

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9310.pdf

**Abstract:**

This paper proposes a periodically time-varying (PTV) inductor applied to a class-D oscillator resulting in a 4.7VDD output swing that effectively improves the phase noise in both 1/f 2 and 1/f 3 regions. Without extra switches, the PTV inductor is realized by reusing the original cross-coupled transistors in the class-D oscillator that semi-periodically cancel the magnetic flux between two coupled inductors. Fabricated in 65nm LP CMOS, the oscillator prototype operating at 0.35V measures FoMs of 192.5±1dBc/Hz at 1MHz offset frequency and 194.6±0.3dBc/Hz at 10MHz offset frequency, over a frequency tuning range from 3.67 to 4.43GHz.

A Periodically Time-Varying Inductor Applied to the Class-D VCO for Phase Noise Improvement

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9176.pdf

**Abstract:**

for automobile applications, a high-switching 48-to-5V DC-DC buck converter is implemented with 0.5μm CMOS process and 0.5μm Gallium-Nitride (GaN)-on-Si process, including the pre-charge tracking technique, temperature-dependent controlled gate driver, and adaptive relaxation gate-drive control technique, which can increase the efficiency by about 8.8% and ensure the current capacity of Enhance-GaN (E-GaN). The inner local negative feedback loop can enhance the reliability and reduce the RON by 12mΩ. The peak efficiency is as high as 95.4%.

A Pre-Charge Tracking Technique in the 40MHz High-Switching 48-to-5V DC-DC Buck Converter with GaN Switches for Reducing Large Self-Commutation Loss and Achieving a High Efficiency of 95.4%

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9148.pdf

**Abstract:**

This paper presents a load-current-regulating OLED driver for wearable light therapy devices. It is based on a single-stage DC-DC hybrid step-up converter architecture achieving high efficiency at a high conversion ratio. The hybrid topology building up the energy through two parallel paths, with an inductor and a capacitor, reduces the loss at a large DC resistance(DCR) of the inductor. Another capacitor reduces switching loss by lowering the voltage stress of switches. The proposed architecture directly regulates the load current without a current-regulation element. 93.21% efficiency is achieved with a large DCR of 200mΩ at a ratio of 4.1.

A Load-Current-Regulating OLED Lamp Driver Using a Hybrid Step-Up Converter with 93.21% Efficiency at a High Conversion Ratio of 4.1

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9316.pdf

**Abstract:**

This paper presents a switching supply modulator that enables the implementation of the challenging cyclic-prefix (CP)-length, supply and load tracking times demanded by 5G new radio (NR) applications. To break the tradeoffs among tracking speed, reliability, efficiency and power density, a Δ-T dual-zone hysteretic control is introduced, which allows the S/L tacking and power conversion to be accomplished in a single and compact power stage. A clock-injected switching spectrum regulation scheme stabilizes switching noise spectrum despite of supply, load or process variation. An IC prototype demonstrates a peak efficiency of 95.4% at 10MHz and achieves a power density of 8.9W/mm2, which, to the best of our knowledge, is 3.2 times higher than the best arts reported. It also achieves record-fast S/L tracking at 810ns/V and 327ns/A respectively, with a full power load of 3.45W.

A 8.9W/mm², 95.4%-Efficiency, CP-Length Tracking Switching Supply Modulator for 5G New Radio mm-Wave PA Arrays

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9053.pdf

**Abstract:**

This paper presents an all-paths inductor-connected buck-converter (APICBC). The APICBC balances conduction losses and has continuous paths-currents for high-frequency switching. Efficiency is optimized over a wide load current range due to the adaptive sizing of the power transistors. The converter has three inductors implemented by bond-wire and PCB patterns and operates with a switching frequency of 100 MHz. The maximum efficiency is 81.2%, and the IC is implemented in a 0.18 μm CMOS process.

A 100-MHz 81.2% All-Paths Inductor-Connected Buck-Converter with Balanced Conduction-Losses and Continuous Path-Currents

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9129.pdf

**Abstract:**

This paper demonstrates complementary 2-D FETs based on molybdenum disulfide, Mos₂, as the active film. The n-type (n-FET) and p-type (p-FET) characteristics are obtained from undoped and Nb-doped Mos₂, respectively. We have achieved similar output current drives and high on-off current ratios of more than 10^6 for both devices. Based on the proposed Mos₂ FET technology, a complementary metal-oxide-semiconductor (CMOS) inverter circuit with a gain of around 20 and 85% total noise margin at a 3 V supply, is integrated, exhibiting the potential of the proposed technology for thin film applications such as in flexible electronic circuits.

Complementary Two-Dimensional (2-D) MoS₂ FET Technology

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9281.pdf

**Abstract:**

In this work, experimental assessment of the variability of threshold voltage and drain current in junctionless nanowire nMOS transistors is presented. Die-to-die variability of threshold voltage and drain current is presented and compared to inversion mode nanowire with the same dimensions. Although the junctionless nanowires have shown larger threshold voltage matching coefficients than inversion mode devices, the variability obtained experimentally has shown to be smaller than predicted by some simulations reported in the literature. Also, it has been shown that as the channel length of junctionless nanowire transistors is reduced, the current variability becomes smaller than in inversion mode nanowires, at the same current level and dimensions.

Experimental Assessment of Variability in Junctionless Nanowire nMOS Transistors

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9078.pdf

**Abstract:**

The improvement of forming gas anneal (10 % H2 in N2) at 400 °C on electrical properties of Ge/GeOx/Tm2O3/HfO2 gate stacks is investigated. It is found that forming gas anneal effectively suppresses fixed charge density, oxide trap density and interface state density. Hydrogen is demonstrated to efficiently passivate the negative fixed charge density and reduce the global variability of the flatband voltage down to 90 mV over a wafer. A forming gas anneal is also found to reduce equivalent oxide thickness in scaled gate stacks.

Improvement on Ge/GeOx/Tm2O3/HfO2 Gate Performance by Forming Gas Anneal

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9069.pdf

**Abstract:**

This paper discusses the effect of back-end of line (BEOL) process on cell performance for a Phase-Change Memory embedded in a 28nm FD-SOI platform (ePCM). The impact of BEOL is first shown by describing the microscopic evolution of the active Ge-rich GST alloy during process. Ge clustering has been proven to occur during the fabrication process, impacting the pristine resistance and the after forming cell performance. Two different BEOL processes are then benchmarked in terms of key performance. An optimized process is then identified, and an extensive electrical characterization of array performance and reliability is performed on the full 16MB chip. The optimized BEOL process results in a memory cell fully compatible with the requirements for demanding automotive applications.

Downloads

Next from ESSCIRC ESSDERC 2021

A 19 GHz Circular-Geometry Quad-Core Tail-Filtering Class-F VCO with -115 dBc/Hz Phase Noise at 1 MHz Offset in 65-nm CMOS

Similar lecture

A Readout Circuit for Tunnel Magnetoresistive Sensors Employing an Ultra-Low-Noise Current Source
